ITEM IS BEING TESTED

This unit is sold. Check for related models on the bottom of the page, or find another Range appliance.

Model
JGBS10DEMWW
Brand
GE
1YR MFG. Warranty
INCLUDED
SOLD

Shipping & Returns

Ask us a Question

Summary

  • Front controls
  • 4.8 cu. ft. oven capacity
  • Sealed cooktop burners
  • Dimensions: 46.25 H x 30 W x 28.75 D
  • ACCESSORIES
    • LP Conversion KitIncluded
  • APPEARANCE
    • Color AppearanceWhite
    • Control KnobsGloss White
    • Cooktop Burner Grate ColorBlack Gloss
    • HandleDesigner Style
    • Oven Door FeaturesOven Window
  • CAPACITY
    • Total Capacity (cubic feet)4.80 cu ft
  • FEATURES
    • Burner - Left Front9,500 BTU
    • Burner - Left Rear9,500 BTU
    • Burner - Right Front13,000 BTU
    • Burner - Right Rear5,000 BTU Precise Simmer
    • ConfigurationRange with Broiler Drawer
    • Control LocationFront
    • Control TypeRotary knobs
    • Cooking TechnologyTraditional
    • Cooktop Burner Grate MaterialHeavy Steel
    • Cooktop Burner TypeSealed
    • Cooktop SurfacePorcelain-Enamel
    • Cooktop TypeStandard Grates
    • Drawer TypeBroiler
    • Fuel TypeNatural Gas
    • Ignition SystemElectronic
    • OU CertifiedNo
    • Oven Cleaning TypeStandard Clean
    • Oven Interior1 Incandescent Light
    • Oven Rack Features2 Flat Nickel Racks
    • Oven Rack Positions (Single or Upper/Lower)6
    • Product TypeFree-Standing Single Oven
    • Sabbath ModeYes
    • Slide - Out Broiler DrawerDrop Down Door
    • Valves (Degree of Turn)140
  • POWER / RATINGS
    • Bake/Broiler BTU Rating - LP (000's BTU's)16.0 Bake / 16.0 Broiler
    • Bake/Broiler BTU Rating - Nat. Gas (000's BTU's)18.0 Bake / 18.0 Broiler
    • Top Burner BTU Rating - LP (000's BTU's)(2) 9.5; (1) 13.0; (1) 5.0
    • Top Burner BTU Rating - Nat. Gas (000's BTU's)(1) 13.0; (2) 9.5, (1) 5.0
    • Volts/Hertz/Amps120v; 60Hz; 15A
  • WARRANTY
    • Labor WarrantyLimited 1-year entire appliance
    • Parts WarrantyLimited 1-year entire appliance
    • Warranty NotesSee written warranty for full details
  • WEIGHTS & DIMENSIONS
    • Approximate Shipping Weight165 lb
    • Cabinet Width30 in
    • Depth with Door Open46.25 in
    • Depth Without Handle26.25 in
    • Height to Cooking Surface (in.)36 - 36.5
    • Net Weight145 lb
    • Oven Interior Dimensions (W x H x D) (in.)24 x 18-1/2 x 19
    • Overall Depth28.75 in
    • Overall Height46.25 in
    • Overall Width30 in

Manufacturer Documents

User Manual
Download Manual
