Summary

Fit Guarantee
No-Preheat Air Fry
Edge-to-edge cooktop
Dimensions: 36.25 H x 30 W x 29.25 D

ACCESSORIES
- Air Fry BasketOptional- JXAFTRAY1VSS
- Center GrateOptional - JXGRATE1
- Griddle AccessoryWB31X28254 (Included) Cast Iron
- LP Conversion KitIncluded
- Optional AccessoriesWB48X21543 Roller Rack
- Trim KitOptional
  JXFILLR1DD
APPEARANCE
- Color AppearanceStainless Steel
- Control KnobsStainless Steel
- Cooktop Burner Grate ColorMatte Black
- HandleDesigner Style
- Handle ColorStainless Steel
- InstallationFlush Appearance
  Free-standing cut-out
- Oven Door FeaturesBig View Oven Window
CAPACITY
- Capacity (Cu. Ft.)2.4 Upper / 4.3 Lower
- Total Capacity (cubic feet)6.70 cu ft
FEATURES
- Burner - Center10,000 BTU Oval
- Burner - Left Front18,000 BTU Power Boil
- Burner - Left Rear5,000 BTU Precise Simmer
- Burner - Right Front15,000 BTU
- Burner - Right Rear9,500 BTU
- ConfigurationDouble Oven Range
- Control LocationFront
- Control TypeElectronic Touch
- Cooking SystemTrue Convection
- Cooking TechnologyTraditional Upper; True Convection Lower
- Cooktop Burner Grate FeaturesContinuous Grates
  Dishwasher Safe
- Cooktop Burner Grate MaterialHeavy Cast Iron
- Cooktop Burner TypeSealed
- Cooktop SurfaceEdge-to-Edge
  Deep Recessed
  Stainless Steel
- Cooktop TypeContinuous Grates
- Fuel TypeNatural Gas
- GriddleCast Iron
- GrillJXCGRILL1
  Optional
- Ignition SystemElectronic
- OU CertifiedNo
- Oven Cleaning TypeSteam Clean
- Oven Control FeaturesAudible Preheat Signal
  Sabbath Mode
  Control Lock Capability
  Electronic Clock & Kitchen Timer
  Steam Clean
- Oven Cooking ModesNo Preheat Air Fry
- Oven Interior1 Auto Incandescent Light
  Gray
- Oven Rack Features3 Oven Racks
- Power Boil BurnerYes
- Product TypeSlide-In Double Oven
- Sabbath ModeYes
POWER / RATINGS
- Bake/Broiler BTU Rating - LP (000's BTU's)7.0 / 120V Bake Assist Element (Upper); 13.5 / 13.5 (Lower)
- Bake/Broiler BTU Rating - Nat. Gas (000's BTU's)7.0 / 120V Bake Assist Element (Upper); 16.5 / 14.0 (Lower)
- Top Burner BTU Rating - LP (000's BTU's)(1) 18.0; (1) 15.0; (1) 8.0; (1) 9.5; (1) 5.0
- Top Burner BTU Rating - Nat. Gas (000's BTU's)(1) 18.0; (1) 15.0; (1) 9.5; (1) 5.0; (1) 10.0
- Volts/Hertz/Amps120v; 60Hz; 15A
WARRANTY
- Labor WarrantyLimited 1-year entire appliance
- Parts WarrantyLimited 1-year entire appliance
- Warranty NotesSee written warranty for full details
WEIGHTS & DIMENSIONS
- Approximate Shipping Weight291 lb
- Cabinet Width30 in
- Cooktop Width30
- Depth with Door Open43.875 in
- Depth Without Handle26.75 in
- Height to Cooking Surface (in.)36.25 +/- .25
- Height to Top of Rear Vent Trim37.375 in
- Net Weight271 lb
- Oven Interior Dimensions (W x H x D) (in.)24 x 9-1/2 x 19-1/8 - Upper; 24 x 15 x 20-5/8 - Lower
- Overall Depth29.25 in
- Overall Height36.25 in
- Overall Width30 in

Manufacturer Documents

User Manual: Download Manual
